XD 5-12kW

Max. Efficiency 97.5%
Max. PV Input Voltage 550V
150% Peak Output Power
2 MPP Trackers, 150% DC Input Oversizing
Max. PV Input Current 16A, Compatible with High Power Modules

Inquiry now

product introduction

	XD5KTR	XD6KTR	XD8KTR	XD10KTR	XD12KTR
Input（PV）
Max. PV Input Power	8kW	9.6kW	12.8kW	16kW	19.2kW
Max. PV Input Voltage	1100V
Start-up Voltage	160V
Rated Voltage	600V
MPPT Voltage Range	150V - 1000V
Number of MPP Trackers	2
Number of String per MPPT	1/1
Max. PV Input Current	20A
Max. Short Circuit Current per MPPT	40A
Output（AC）
Rated Output Power	5kVA	6kVA	8kVA	10kVA	12kVA
Max. Output Power	5.5kVA	6.6kVA	8.8kVA	11kVA	13.2kVA
Max. Output Current	7.2A	8.7A	11.6A	14.5A	17.4A
Rated Voltage	230V / 400V
Rated Frequency	50Hz / 60Hz
THDi(@Rated Power)
Power Factor	0.8 leading~0.8 lagging
Output（EPS）
Max. Output Power	5.5kVA	6.6kVA	8.8kVA	11kVA	13.2kVA
Peak Output Power，Time	10kW, 60s	12kW, 60s	16kW, 60s	20kW, 60s	20kW, 60s
Rated Voltage, Frequency	230V / 400V, 50Hz
THDv(@Rated Power)	＜3%
Switch Time	＜10ms
Battery
Battery Type	Lithium, Lead-acid
Battery Voltage Range	160V - 800V
Max. Charge / Discharge Current	50A
Communication	CAN / RS485
Efficiency
Max. Efficiency	＞98.2%			＞98.4%
EU Efficiency	＞97.6%			＞97.8%
Battery Charge / Discharge Efficiency	＞97.6%			＞97.8%
Protection
DC Switch	Yes
DC Reverse Polarity Protection	Yes
Anti-islanding Protection	Yes
AC Short Circuit Protection	Yes
Residual Current Monitoring	Yes
Insulation Resistance Monitoring	Yes
Ground Fault Monitoring	Yes
Over Current / Voltage Protection	Yes
I-V Curve Scan	Yes
Battery Soft Start Protection	Yes
Surge Protection	Type II
AFCI Protection	Optional
Communication
Display	LCD
Communication	RS485 / CAN / WIFI / 4G / LAN / Bluetooth
General Data
Dimension（W x H x D）	534 x 440 x 220 mm
Weight
Operating Temperature Range	-30℃～+60℃
Cooling Method	Natural
Protection Degree	IP66
Max. Operating Altitude	4000m
Noise	≤35dB
Relative Humidity	0~100%
Self-consumption	＜10W
Topology	Transformerless
